RODUCT FEATURES :

Five-core wire connection: AC90-220V electrical control can be achieved, regardless of whether the AC90-220V electrical control wire is electrified or not, it can be achieved by remote control, dry contact control and hand-pull start function.

Note: Electrical control wire voltage AC90~240V, 50/60HZ

When the red wire is connected, the black wire is disconnected, the motor is rotating; when the black wire is connected, the red wire is disconnected, the motor is reversing.

*Working environment: -5℃~45℃

*Rated power: 20W

*Rated torque: 2.0N·m

*Support connecting with smart curtain switch/smart curtain module to be smart
